Electra intercom

125 kHz RFID
#9

Hi there. I am from Romania too, I have same problem with Electra Intercoms. I have wrote the original Electra key on a blank rewritable EM4100. But it seams to be a problem with the key that are not originally from Electra.

I have checked the token. I have the same token on both keys but the copied key is not read by the reader. I mean there is no feedback from reader, no buzzing, no lighting nothing.

I was thinking to make a copy at special key copy center or to ask them for buying a blank key from them.

@philiplykov you can check in any Mall Shopping Center and also in Dedeman for a key copy stand.

1 Like
#10

Hi! I’m in Moldova. I believe they extended the protocol by somehow (on physical or data link layer), so it could be extension/modification of LFrfid or EM4100.
I will be glad to help with debugging but don’t know how.

1 Like
#11

Maybe reading RAW on those fobs/cards would help develloper team to figure out what is going on ? Maybe flipper do see the card as EM4100 and ignores possible data that the card does have apart from the traditional/standard EM4100 data ?

#12

any news on this topic?

1 Like
#13

Still no success. Dev team doesn’t react.

#14

I have the same problem, i can read the tag and program another one that is not from electra but that one cannot open the door.
But i found the data sheet: https://www.nxp.com/docs/en/data-sheet/HTSICH56_48_SDS.pdf
It seems to have some security functions

3 Likes
#15

I found on Softpedia something about these tags:
The tags manufactured after 2010 cannot be copied, because they have 1 additional bit. Tags without that additional bit works only on old readers.

On my apartment I found out that the emulated card works with electra intercom, but only on secondary door where I have a card reader that is not sold by electra, but is connected to Electra intercom.

So we need support to read & emulate that additional bit.

3 Likes
#16

Good!

1 Like
#17

Maybe get a RAW reading of the card with the extra bit and send to @Astra to see if it can be implemented ?

#18

Hello.

Any update so far?

I am also from Romania and i am having the same issue with Electra. I can read the keytag with RFID but when trying to emulate the door reciver doesn’t respond in any way.

..jpg1080×728 44.8 KB

1 Like
#19

@Astra it is anything that can be done about this? I can offer any kind of info you need. Thx.

2 Likes
#20

I have the same issue. Same electra intercom : nothing happen when i am trying to open the door.

2 Likes
#21

Hello! Similar problem. Bought about 5-6 different tags. Clone and burn, I can. But the electra intercom does not read them, just like Flipper emulation itself.

1 Like
#22

Same issue - electra is the first intercom that doesn’t work for me :slight_smile:

1 Like
#23

so mo help ? its so wierd that electra not working with anything than electra tag ,it you go to a cloning shop they can make clones very easy. i have done in it

1 Like
#24

Bump this! A whole country depends on it, maybe we can send you some demo keys guys ? Or order some online ? This needs to be looked at in some way or another, its a very powerful tool to have and without it you cant hack 90% of the keys here.

2 Likes
#25

Hello! I also have problems with electra tags. Is there anything we can do to help the development team?

1 Like
#27

I have found out some more information, it seems like older Electra systems work with this no problem, on the newer ones it says it works only with Electra tags as I found in the oficial documentation. So lets analyze what i’ve found. It seems newer Electra systems are not compatible with flipper emulation, but going deeper it seems the Flipper gets detected somehow, given the fact I can hear a small click when I get close to the reader, something like a pin resting but after that on the second try I cant detect any noise, not even the reader saying its incorrect. But funny enough if you try an older tag the reader types “Acces Denied”, i think this works even if its not an Electra tag (tried it with an older Electra tag I had). The Flipper seems like not being able to emulate the tag for whatever reason. But why does it seems to read all other tags except the Flipper? Someone needs to test if you can write an electra tag with the master key and open the door. The master key for the ones I’ve opened is FF:FF:FF:FF:FF. Also some other readers were present on other locations tested which worked wonderful including an NFC reader on some locations which seems to not be detected by the Flipper NFC Detect Reader function but Il post that to the NFC topic when I find more information.

2 Likes
#28

Also today I found out you cant write a blank key from Electra using the Flipper, they use a device sold by Electra. Also the RFID tag has 3 codes, one code that is the basic code, one installer code ( this is written on the box of the Electra cloning equipment when bought), and one private code which must be a security measure taken by Electra to stop cloning. So I saved the FF:FF:FF:FF:FF code to the flipper and visited the nearest key shop and told them to copy the Flipper code to the tag ( they also told me that they cant make a custom code like the one I’ve found and a key needs to be copied, also the code was displayed as a string of numbers like “2365916492” or something like this) so I gave them my Flipper which they scanned ( a prompt popped saying that it was a Chinese copy of the tag) and then they transferred this to the tag which when read with the Flipper displays FF:FF:FF:FF:FD instead of the code provided. (I’ve tried this twice). I know dev’s are busy but maybe someone from the dev team might shed some light on this matter. Also all help is welcome so don’t hold back. :grin:
Also this is the installation tutorial of the intercom and some photos from my flipper :

IMG_3457
IMG_3457777×385 63.2 KB

IMG_3458
IMG_3458786×395 60.6 KB

3 Likes
#29

up up up :slight_smile: we needs to find a way

2 Likes
